    Customized 2D Rigid Phlogopite Mica Plate For EV Battery Thermal Insulation

    Ask Lasest Price
    Brand Name : YT Mica / YiTian Mica
    Model Number : YT Mica / phlogopite mica sheet / rigid mica sheet for EV battery
    Certification : ROHS/ SGS/ REACH
    Payment Terms : L/C, T/T
    Delivery Time : 5-10 days
    • Product Details
    • Company Profile

    Customized 2D Rigid Phlogopite Mica Plate For EV Battery Thermal Insulation

    Mica Spare Part For EV Battery Thermal Insulation / 2D Rigid Phlogopite Mica Plate


    Mica Spare Part For EV Battery Thermal Insulation is composed of 2D mica plate and completely back-glued tape.


    Phlogopite mica sheet
    HP5
    PropertiesDescriptionUnit
    ColorGolden/
    Thicknesscustomizedmm
    Density1.6—2.5g/m²
    Yield Strength≥100Mpa
    Dielectric Strength≥15kv/mm
    Resistivity≥1.0*10^10MΩ·m
    Moisture Absorption≤1.5%
    Thermal Conductivity≤0.4W/m·K
    Flame RetardanceV0/
    Fire Resistance1000 fire not burn through within 5 mins/

    Mica insulation material is used for insulation between battery cells. It can separate the battery cells from the assembly according to the multi-dimensional design of the battery module structure, and has the advantages of tight fitting, simple & easy for assembly.


    Mica products are mainly used as thermal control and battery protection materials for power batteries in the EV industry. Mica are important protection materials for thermal control of power batteries in new EV. Mica insulation materials are the last line of defense against thermal runaway of batteries, ensuring that people in the vehicle have enough safety escape time.


    YT MICA fully implement the ISO 9001-2015 quality system operation,as a stan- dardization of internal management,strengthen the system building an important measure.A strict quality control system has been established,from raw materials, processes, finished products inspection,to ensure that every link in the production process is strictly in accordance with the standards for testing.


    YT Mica has equipped with various fire-resistant testing devices and can assist customers in developing fire-resistant cable products according to different standards of various countries, providing one-stop solution service.


    1. According to different requirements, we have compiled a total of 64 testing items for mica products, including physical properties, electrical properties, thermal properties, aging properties, and flame retardant properties, which basically cover all the requirements for mica performance testing;


    2. At present, YT MICA is capable to detect 50 items of the testings and provide theoretical support quickly for different application scenarios of mica products.


    Mica Testings for EV Industry as below:


    ItemPropertyTesting itemsTesting criteriaTested by
    1Physical PropertyMica contentIEC 60371YT Mica Internal Test
    2Glue contentIEC 60371
    3DensityIEC 60371
    4ThicknessThickness Gauge Test
    5Water AbsorptionISO 62
    6DelaminationGB/T 5019.2-2009
    7TGA(Thermal Gravimetry Analysis)IEC603713rd PartyTest
    8Linear expansion coefficient (length direction) thickness directionASTM E8313rd PartyTest
    9Back glued performancePeel off strengthASTM D3330YT Mica Internal Test
    10Fire retardanceFlame retardanceUL943rd PartyTest
    11CleannessCleanessVDA19,ISO162323rd PartyTest
    12Thermal PropertyThermal conductivityASTM E14613rd PartyTest
    13Heat CapacityISO 113573rd PartyTest
    14Fire Resistance1200±100℃,30minYT Mica Internal Test
    15Mechanic Property25℃ Bending StrengthISO 178YT Mica Internal Test
    1625℃Bending ModulusISO 178
    17-40℃ Bending StrengthISO 178
    1825℃ Tensile StrengthISO 527
    1925℃ Section ElongationISO 527
    2025℃ Tensile ModulusISO 527
    21Impact / Shock StrengthISO 179:20103rd PartyTest
    ItemPropertyTesting itemsTesting criteriaTested by
    22Electrical propertiesInsulation resistanceIEC 60093/IEC 62631-3YT Mica Internal Test
    23Volume resistivityGB/T1410-2006YT Mica Internal Test
    24Dielectric StrengthIEC 60243YT Mica Internal Test
    25Withstand voltage testGB/T1408-2016YT Mica Internal Test
    26Comparative Tracking lndex(CTI)IEC 601123rd PartyTest
    27Ecologic performanceHazardous substancesRoHS2.0 & REACH & ELV3rd PartyTest
    28Aging performance 85/85, 1000h, after the test completed, 2 hours standby at room temperatureVisual InspectionYT Mica Internal Test
    29Dimension ControlYT Mica Internal Test
    30Weight ControlYT Mica Internal Test
    31Water AbsorptionISO 62YT Mica Internal Test
    32Tensile StrengthIEC 60371-2/GBT 5019.2YT Mica Internal Test
    33Bending StrengthISO 178YT Mica Internal Test
    34Dielectric StrenghtIEC 60243YT Mica Internal Test
    35Insulation resistanceIEC 60093/IEC 62631-3YT Mica Internal Test
    36Withstand voltage testGB/T1408-2016YT Mica Internal Test
    37Thermal conductivityGB/T 10294-20083rd PartyTest
    38Flame retardanceUL943rd PartyTest

    Yitian Mica has obtained 5 invention patents, 21 practical patents, 20 software registration rights, and 3 trademarks. More intellectual property rights has been applied for verification.


    YTMICA 5 invention patents:
    a mica insulation material for battery cells and its processing & application.
    a squeeze-resistant fireproof mica tape for power batteries and its processing & application.

    high-temperature resistant mica tape & mica thermal insulation parts and their production methods.
    a processing method for fire-resistant mica tape.
    a fire-resistant insulation tape for optical cables.


    YT MICA System certifications obtained:
    ISO9001 Quality Management System Certificate
    ISO14001 Environmental Management System Certificate
    ISO45001 Certificate of Occupational Health&Safety Management
    IATF 16949 Quality Management System certificate
    SA8000 Social Responsibility Management System Certificate


    YT Mica has a dedicated R&D department working on innovations and the development of your projects. It is our longstanding experience with processing natural mica that allows us to provide tailor-made solutions for our end customers. Our product development and application engineering specialists will be in close cooperation with our customers to identify their needs and meet their specific requirements. If we don't have an immediate solution for you, our R&D department will work with you to develop and deliver the best possible solution that will meet your needs.


    We have invested and developed expertise in machining, drilling, cutting, sawing and punching, thermal pressing/stamping our products to provide the best solutions to our customers. From our home made mica sheets we can manufacture pieces according to your technical specifications.
